AR31, ARS220 & 350 Series QR Couplings
Part No: 0212002010
- 3/8"BSPF thread
- 280 Bar rated pressure
- 50 Lpm max flow
- 150°C rated temperature
- Chrome plated brass body
- NBR O rings
Part No: I00700012
- 1/4"BSPF thread
- 280 Bar rated pressure
- 50 Lpm max flow
- 150°C rated temperature
- Chrome plated brass
- ø19.9mm plug
Part No: 0121730070
- 3/8"BSPF thread
- 280 Bar rated pressure
- 50 Lpm max flow
- 150°C rated temperature
- Chrome plated brass
- ø19.9mm plug
Part No: 26.2030.00
- 3/8"BSPF thread
- 220 Bar rated pressure
- 50 Lpm max flow
- 90°C rated temperature
- Nickel plated brass body
- NBR O rings
Part No: 26.2030.80
- M22x1.5F thread
- 220 Bar rated pressure
- 50 Lpm max flow
- 90°C rated temperature
- Nickel plated brass body
- NBR O rings
Part No: 26.2050.20
- 1/4"BSPF thread
- 350 Bar rated pressure
- 50 Lpm max flow
- 90°C rated temperature
- Stainless steel body
- Viton O rings
Part No: 26.2050.25
- 1/4"BSPM thread
- 350 Bar rated pressure
- 50 Lpm max flow
- 90°C rated temperature
- Stainless steel body
- Viton O rings
Part No: 26.2050.00
- 3/8"BSPF thread
- 350 Bar rated pressure
- 50 Lpm max flow
- 90°C rated temperature
- Stainless steel body
- Viton O rings
Part No: 26.2040.51
- 1/4"BSPF thread
- 350 Bar rated pressure
- 50 Lpm max flow
- 90°C rated temperature
- Stainless steel
- ø19.9mm plug - ø12mm internal bore
Part No: 26.2045.51
- 1/4"BSPM thread
- 350 Bar rated pressure
- 50 Lpm max flow
- 90°C rated temperature
- Stainless steel
- ø19.9mm plug - ø12mm internal bore
Part No: 26.2035.51
- 3/8"BSPF thread
- 350 Bar rated pressure
- 50 Lpm max flow
- 90°C rated temperature
- Stainless steel
- ø19.9mm plug - ø12mm internal bore
Part No: 26.2048.51
- 3/8"BSPM thread
- 350 Bar rated pressure
- 50 Lpm max flow
- 90°C rated temperature
- Stainless steel
- ø19.9mm plug - ø12mm internal bore
