Comet APS Series Pumps
Part No: 6115000100
- 40 Bar max
- 28 Lpm max
- 550 Rpm
- 2.7 Hp, 2.0 kW
- 6 hole flange for stub shaft
- NBR diaphragms
Part No: 6114000100
- 40 Bar max
- 41 Lpm max
- 550 Rpm
- 4.1 Hp, 3.0 kW
- 6 hole flange
- Anodised aluminium head
Part No: 6090002000
- 40 Bar max
- 53.9 Lpm max
- 550 Rpm
- 5.2 Hp, 3.8 kW
- 1"3/8M x 1"3/8M 6 splined thru shaft
- NBR diaphragms
Part No: 6090002200
- 40 Bar max
- 53.9 Lpm max
- 550 Rpm
- 5.2 Hp, 3.8 kW
- 6 hole flange for stub shaft
- NBR diaphragms
Part No: 6090000400
- 40 Bar max
- 53.9 Lpm max
- 550 Rpm
- 5.2 Hp, 3.8 kW
- For engine/motor drive*
- NBR diaphragms
Part No: 6092002000
- 40 Bar max
- 71.3 Lpm max
- 550 Rpm
- 9.1 Hp, 6.7 kW
- 1"3/8M x 1"3/8M 6 splined thru shaft
- NBR diaphragms
Part No: 6092002100
- 40 Bar max
- 71.3 Lpm max
- 550 Rpm
- 9.1 Hp, 6.7 kW
- 6 hole flange for stub shaft
- NBR diaphragms
Part No: 6094001900
- 50 Bar max
- 100 Lpm max
- 550 Rpm
- 12.3 Hp, 9.0 kW
- 1"3/8M x 1"3/8M 6 splined thru shaft
- NBR diaphragms
Part No: 6096000500
- 50 Bar max
- 145 Lpm max
- 550 Rpm
- 17.8 Hp, 13.1 kW
- 1"3/8M x 1"3/8M 6 splined thru shaft
- NBR diaphragms
Part No: 6097000600
- 50 Bar max
- 169 Lpm max
- 550 Rpm
- 20.5 Hp, 18.4 kW
- 1"3/8M x 1"3/8M 6 splined thru shaft
- NBR diaphragms
