Pressure Switches
Part No: SIMPLEX
- 50-200 Bar pressure
- 30 Bar switch pressure
- 250V 5(1) Amp IP55 switch
- 60°C rated temperature
- 1/4"BSPM inlet
- 1400mm cable
Part No: 29.0080.00
- 250 Bar rated pressure
- 25 Bar switch pressure
- 250V 6(2) Amp - IP55
- 75°C rated temperature
- 1/4"BSPM inlet
- Brass nipple
Part No: 0205007000
- 250 Bar rated pressure
- 15 Bar switch pressure - Blue
- 250V 16(6) Amp - IP55
- 75°C rated temperature
- 1/4"BSPM inlet
- Brass nipple
Part No: 0205007010
- 250 Bar rated pressure
- 25 Bar switch pressure - Red
- 250V 16(6) Amp - IP55
- 75°C rated temperature
- 1/4"BSPM inlet
- Brass nipple
Part No: 0205007020
- 250 Bar rated pressure
- 45 Bar switch pressure - Black
- 250V 16(6) Amp - IP55
- 75°C rated temperature
- 1/4"BSPM inlet
- Brass nipple
Part No: 0205007030
- 250 Bar rated pressure
- 25 Bar switch pressure - Red
- 250V 16(6) Amp - IP55
- 75°C rated temperature
- 3/8"BSPM inlet
- Brass nipple
Part No: 0205007040
- 250 Bar rated pressure
- 45 Bar switch pressure - Black
- 250V 16(6) Amp - IP55
- 75°C rated temperature
- 3/8"BSPM inlet
- Brass nipple
Part No: 29.0040.15
- 250 Bar rated pressure
- 25 Bar switch pressure - Red
- 250V 16(6) Amp - IP55
- 90°C max fluid temperature
- 3/8"BSPM inlet
- Brass nipple
