Multi-Stage Centrifugal Pumps
<
1 of 2
>
Part No: 265300001
- 74m max head
- 160 Lpm max flow
- Non self-priming
- 230V, 12.5A, 3.0 Hp electric motor
- Automatic pump controller
- 1.5 Bar starting pressure
Part No: 193315000
- 103m max head
- 80 Lpm max flow
- Non self-priming
- 230 Volt 1.5 Hp electric motor
- Cast iron suction body, nitrile seals
- 1"1/2 female pump inlet
Part No: 193325000
- 161m max head
- 80 Lpm max flow
- Non self-priming
- 230 Volt 2.5 Hp electric motor
- Cast iron suction body, nitrile seals
- 1"1/2 female pump inlet
Part No: 193615000
- 74m max head
- 150 Lpm max flow
- Non self-priming
- 230 Volt 1.5 Hp electric motor
- Cast iron suction body, nitrile seals
- 1"1/2 female pump inlet
Part No: 193625000
- 110m max head
- 150 Lpm max flow
- Non self-priming
- 230 Volt 2.5 Hp electric motor
- Cast iron suction body, nitrile seals
- 1"1/2 female pump inlet
Part No: 193625250
- 110m max head
- 150 Lpm max flow
- Non self-priming
- 400 Volt 2.5 Hp IE3 electric motor
- Cast iron suction body, nitrile seals
- 1"1/2 female pump inlet
Part No: 193915000
- 58m max head
- 200 Lpm max flow
- Non self-priming
- 230 Volt 1.5 Hp electric motor
- Cast iron suction body, nitrile seals
- 1"1/2 female pump inlet
Part No: 193920200
- 64m max head
- 200 Lpm max flow
- Non self-priming
- 400 Volt 2 Hp IE3 electric motor
- Cast iron suction body, nitrile seals
- 1"1/2 female pump inlet
Part No: 193925000
- 76m max head
- 200 Lpm max flow
- Non self-priming
- 230 Volt 3 Hp electric motor
- Cast iron suction body, nitrile seals
- 1"1/2 female pump inlet
Part No: 193925250
- 76m max head
- 200 Lpm max flow
- Non self-priming
- 400 Volt 3 Hp IE3 electric motor
- Cast iron suction body, nitrile seals
- 1"1/2 female pump inlet
Part No: 193123050
- 73m max head
- 250 Lpm max flow
- Non self-priming
- 400 Volt 3 Hp IE3 electric motor
- Cast iron suction body, nitrile seals
Part No: 197060901
- 66.8m max head
- 133 Lpm max flow
- Non self-priming
- 230 Volt 1.1 kW, 1.5 Hp electric motor
- S1 duty - Class F - IP55 motor
- 9x AISI304 stainless steel impellers
<
