Pressure Regulating Valves - Up to 100 Bar
<
2 of 2
>
Part No: 8384014
- 20 Bar max pressure
- 200 Lpm max flow
- 60°C max temperature
- Mount in line
- PA66-GF50 reinforced nylon body
- AISI431 stainless steel internals
Part No: 8384049
- 20 Bar max pressure
- 400 Lpm max flow
- 60°C max temperature
- Mount in line
- PA66-GF50 reinforced nylon body
- AISI431 stainless steel internals
Part No: 401-1020
- 15 Bar max pressure
- 600 Lpm max flow
- Mount in line
- Fibreglass reinforced nylon body
- Buna seals
- 2"BSP male ports
Part No: 60.0560.30
- 5-30 Bar rated pressure
- 14 Lpm max flow
- 90°C rated water temperature
- Brass body - St.steel internals
- Not preset, see manual
- 1/4"BSPM inlet
Part No: 60.0560.00
- 14-140 Bar rated pressure
- 14 Lpm max flow
- 90°C rated water temperature
- Brass body - St.steel internals
- Not preset, see manual
- 1/4"BSPM inlet
Part No: ART555-35
- 35 Bar max pressure
- 35 Lpm max flow
- 80°C rated water temperature
- Mount off line on a tee
- Brass body - Blue spring
- Stainless steel internals
Part No: ART555-70
- 70 Bar max pressure
- 35 Lpm max flow
- 80°C rated water temperature
- Mount off line on a tee
- Brass body - Red spring
- Stainless steel internals
Part No: ART556-35
- 35 Bar max pressure
- 25 Lpm max flow
- 80°C rated water temperature
- Mount in line
- Brass body - Blue spring
- Stainless steel internals
Part No: ART556-70
- 70 Bar max pressure
- 25 Lpm max flow
- 80°C rated water temperature
- Mount in line
- Brass body - Red spring
- Stainless steel internals
Part No: 60.0220.00
- 10-100 Bar rated pressure
- 30 Lpm max flow
- 90°C rated temperature
- Mount off line on a tee
- Brass body - St.steel internals
- Not preset, see manual
Part No: TIMAX
- 60 Bar max pressure
- 200 Lpm max flow
- 60°C max water temperature
- Manual bypass lever
- Brass body - St.steel internals
- 3/4"BSPF inlet
Part No: TIMAX100
- 100 Bar max pressure
- 200 Lpm max flow
- 60°C max water temperature
- Manual bypass lever
- Brass body - St.steel internals
- 3/4"BSPF inlet
<
