High Pressure Swivels - Up to 600 Bar
Part No: 31.001
- 1/4"BSPF inlet
- 1/4"BSPM outlet
- 275 Bar max pressure
- 30 Rpm max @ 120°C
- 1000 Rpm max @ 30°C
- Nickel plated brass body
Part No: 31.002
- 1/4"BSPF inlet
- 1/4"BSPF outlet
- 275 Bar max pressure
- 30 Rpm max @ 120°C
- 1000 Rpm max @ 30°C
- Nickel plated brass body
Part No: 31.003
- 1/4"BSPF inlet
- 3/8"BSPM outlet
- 275 Bar max pressure
- 30 Rpm max @ 120°C
- 1000 Rpm max @ 30°C
- Nickel plated brass body
Part No: 31.101
- 3/8"BSPF inlet
- 1/4"BSPM outlet
- 275 Bar max pressure
- 30 Rpm max @ 120°C
- 1000 Rpm max @ 30°C
- Nickel plated brass body
Part No: 31.103
- 3/8"BSPF inlet
- 3/8"BSPM outlet
- 275 Bar max pressure
- 30 Rpm max @ 120°C
- 1000 Rpm max @ 30°C
- Nickel plated brass body
Part No: 31.104
- 3/8"BSPF inlet
- 3/8"BSPF outlet
- 275 Bar max pressure
- 30 Rpm max @ 120°C
- 1000 Rpm max @ 30°C
- Nickel plated brass body
Part No: 26.1060.00
- 1/4"BSPM taper inlet
- 1/4"BSPF outlet
- 350 Bar rated pressure
- 40 Lpm max flow
- 90°C max working temperature
- 160°C rated temperature
Part No: 26.1061.00
- 3/8"BSPM taper inlet
- 3/8"BSPF outlet
- 350 Bar rated pressure
- 40 Lpm max flow
- 90°C max working temperature
- 160°C rated temperature
Part No: 22.0435
- 3/8"BSPM inlet
- 3/8"BSPF outlet
- 400 Bar rated pressure
- 45 Lpm max flow
- 160°C rated temperature
- Stainless steel body
Part No: 30.5840.00
- 3/8"BSPF inlet
- 3/8"BSPM outlet
- 600 Bar rated pressure
- 60 Lpm max flow
- 100°C rated temperature
- 30 Rpm max speed
