Hose Reel Swivels
<
1 of 2
>
Part No: 299-1016
- 9-13mm hose barb
- 3/4"BSPF thread
- 10 Bar max pressure
- Brass construction
Part No: 500-1050
- 16/19mm hose barb
- 3/4" female thread
- 10 Bar max pressure
- Brass construction
Part No: MPR0576
- 1/2"BSP male outlet
- 3/4"BSP female inlet
- 10 Bar max pressure
- Brass
- Supplied with gasket
Part No: 500-1007
- Male QR swivel adaptor
- 3/4" female thread
- 10 Bar max pressure
- Brass construction
Part No: 0636GX
- 20 Bar max pressure
- AISI303 stainless steel
- Viton seals
- Inlet 1"BSPM
- Outlet 1"BSPF
- Supplied w/ 1" elbow
Part No: 0065A
- 60 Bar max pressure
- Zinc plated steel
- Polyurethane seals
- Inlet 3/4"BSPM - ø12mm od pin
- Outlet 3/4"BSPF
- Suitable for air, oil & water
Part No: 0065C
- 60 Bar max pressure
- Zinc plated steel
- Buna seals
- Inlet 3/4"BSPM - ø16mm od pin
- Outlet 1/2"BSPTM w/ 60° cone
- Suitable for water only
Part No: 0065CX
- 60 Bar max pressure
- AISI303 stainless steel
- Buna seals
- Inlet 3/4"BSPM - ø16mm od pin
- Outlet 1/2"BSPTM w/ 60° cone
- Suitable for water only
Part No: 0065D
- 60 Bar max pressure
- Zinc plated steel
- Polyurethane seals
- Inlet 3/4"BSPM - ø16mm od pin
- Outlet 1/2"BSPTM w/ 60° cone
- Suitable for air, oil & water
Part No: 22.0206
- 275 Bar max pressure
- 30 Lpm max flow
- Brass construction
- 1/2"NPTM inlet
- 3/8"BSPF outlet
Part No: 22.0207
- 275 Bar max pressure
- 30 Lpm max flow
- Brass construction
- M27x2M inlet
- 3/8"BSPF outlet
Part No: 0066B
- 400 Bar max pressure
- Zinc plated steel
- Silicon PTFE seals
- Inlet 3/4"BSPM - ø11mm od pin
- Outlet 3/8"BSPF
- Suitable for water only
<
