Comet Gearboxes for Electric & Engine Drive
Part No: 5011018300
- For MC8, MC18 pumps
- To mount to 3/4" shaft engine
- Suitable for Honda GX120-200
Part No: 5011027900
- For MC20, MC25 pumps*
- To mount to 3/4" shaft engine
- Suitable for Honda GX120
- ΓΈ16mm spiral splined shaft
- *model nos 6084007100 & 6084007200 only
Part No: 5005021600
- For MP20, MP30, P40, P48/AP, P50, APS31, APS41 & APS51 pumps
- To mount to 3/4" shaft engine
- SAE J609A flange, extension 3
- 1:6.44 ratio
- 3600 rpm
- Suitable for Honda GX120-200
Part No: 5005022600
- For BP75, BP60K, BP105K & BP125K pumps
- To mount to 3/4" shaft engine
- SAE J609A flange, extension 3
- 1:6.44 ratio
- 3600 rpm
- Suitble for Honda GX120-200
Part No: 5005022100
- For P48/AP, P50, APS41, APS51, APS61, APS71 pumps
- To mount to 1" shaft engine
- SAE J609A flange, extension 4
- 1:6.44 ratio
- 3600 rpm
- Suitable for Honda GX240-270
Part No: 5005022700
- For BP105K & BP125K pumps
- To mount to 1" shaft engine
- SAE J609A flange, extension 4
- 1:6.44 ratio
- 3600 rpm
- Suitable for Honda GX240-270
Part No: 5005023000
- For MP20, MP30, P48/AP, P50, APS31, APS41, APS51 pumps
- 1:6.44 ratio
- 3600 rpm
- Suitable for Lombardini 15LD
Part No: 5005021900
- For MP20, MP30, P40 & APS31 pumps
- To mount to 90 frame motor
- 1:5.09 ratio
- 2800 rpm, 2 pole
Part No: 5005021700
- For MP20, MP30, P40 & APS31 pumps
- To mount to 100-112 frame motors
- 1:5.09 ratio
- 2800 rpm, 2 pole
Part No: 5005022800
- For BP75, BP60K, BP105K & BP125K pumps
- To mount to 100-112 frame motors
- 1:5.09 ratio
- 2800 rpm, 2 pole
Part No: 5005021800
- For P48/AP, P50, APS51, APS61 & APS71 pumps
- To mount to 100-112 frame motors
- 1:5.09 ratio
- 2800 rpm, 2 pole
